Model: PRIME A520M-K
CPU: AMD AM4 Socket for AMD Ryzen� 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors
Chipset: AMD A520
Memoria: 2 x DIMM, Max. 64GB, DDR4 4866(O.C)/4600(O.C)/4466(O.C.)/4400(O.C)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory *
Dual Channel Memory Architecture
Gr�ficos: 1 x D-Sub, 1 x HDMI 2.1(4K@60HZ)
Slots de Expansi�n: AMD Ryzen� 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors, 1 x PCIe 3.0 x16 (x16 mode), AMD A520 Chipset, 2 x PCIe 3.0 x1
Almacenamiento:
Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports
AMD Ryzen� 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
AMD A520 Chipset: 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 10
LAN: Realtek RTL8111H 1Gb Ethernet, ASUS LANGuard
Audio: Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC
Puertos USB: Rear USB Port ( Total 6 ): 4 x USB 3.2 Gen 1 port(s)(4 x Type-A), 2 x USB 2.0 port(s)(2 x Type-A)
Front USB Port ( Total 6 ): 2 x USB 3.2 Gen 1 port(s)(2 x Type-A), 4 x USB 2.0 port(s)(4 x Type-A)
Puertos I/O Traseros:
1 x PS/2 keyboard/mouse combo port(s)
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) port(s)
4 x USB 3.2 Gen 1 (blue) Type-A
2 x USB 2.0
3 x Audio jack(s)
Internal I/O
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x SPI TPM header
4 x SATA 6Gb/s connector(s)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin EATX 12V Power connectors
1 x Front panel audio connector(s) (AAFP)
1 x Clear CMOS jumper(s)
1 x System panel connector
1 x COM port header
1 x Speaker connector
Accessorios:
User�s manual
I/O Shield
2 x SATA 6Gb/s cable(s)
1 x Supporting DVD
1 x M.2 SSD screw package(s)
BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
Sistema Operativo: Windows� 10 64-bit
Factor de forma: mATX Form Factor, 8.9 inch x 8.7 inch ( 22.6 cm x 22.1 cm )
